Catamarans
NabCat 1475 HYB
Best seller in the Electric series. NabCat 1475 Electric is equipped with powerful Visedo propulsion machinery and Akazem battery system. Generator and battery capacity can be adjusted as needed. The boat is equipped with a bow thruster. Standard delivery as a plug-in hybrid. Can be delivered on request as a pure electric boat or with conventional propulsion machinery.
| Construction | Catamaran |
| Design | Marin Design |
| Material | Aluminum |
Main Dimensions
| Length o.a. | 14,00 m |
| Breadth o.a. | 7,50 m |
| Breadth hull | 2,20 m |
| Depth moulded | 2,80 m |
Capacities
| Fuel | 1,5 m3 |
| Water | 1 m3 |
| Load capacity deck | Approx. 30 t |
| Gross deck area behind wheelhouse | Approx. 62 m2 |
| Trade area | 4 |
Propulsion machinery*
| Engine | 2 x Visedo PowerDrum PM 105 kW |
| Energy Storage System | 10 pcs AkaZem 15 OEM 333 kWh. The battery capacity is adapted to the needs of each individual project. |
| Gear and propeller | Reducer and propeller in each hull. |
| Bow thruster | 1 x 37 hp electric |
| * Can be ordered with diesel mechanical propulsion machinery |
Generator
| 1 piece customized as needed |
Navigation and communication
| Furuno Radar and chart Plotter with GPS |
| Furuno VHF radio |
| Furuno Echo sounder |
| Autopilot Furuno Navpilot |
| Navtex receiver |
| mLINK monitor |
| Moen IAS |
Crane
| -Palfinger 41002 (M) G Capacity: 38,2 tm Reach: 21,5 m Rotation: Continuous | |
| Scanreco radio control |
Capstans
| 1 x 3 t electric |
| 1 x 5 t electric |
| Both included foot pedals and emergency stops. |
Other
| Prepared for deck winch |
